Saniflo Sanitop Up Macerator Small Bore Pumping System - 6002 – Technical Specifications
Unit Type
Macerator
Application
Toilet & Basin
Available Inlets
2
Clog Resistance
Low
Easy Maintenance
No
Noise Level
46
dB
Maximum Vertical Discharge
5
M
Maximum Horizontal Discharge
100
M
Max Water Temperature (Continuous)
35
C
Max Water Temperature (Intermittent)
35
C
Model
Sanitop Up
EAN
3308811398017
Macerator Colour
White
Macerator Width (mm)
339
Macerator Height (mm)
312
Macerator Depth (mm)
166
Macerator Material
Plastic
Macerator Head
5
Range
Sanitop
MPN
6002
Product Code
166259
Type
Pump
Warranty (Years)
5
Weight (Kg)
5.4
Macerator Output (Watts)
400
Description−
Saniflo Sanitop Up Macerator Small Bore Pumping System
The Saniflo Sanitop is very comparable to the original Saniflo as it physically has all the same features and actions, although, it enables the connection of a WC and a Wash basin to a single pump, delivering simplicity and practicality. The powerful macerator within the product enables waste to be progressed up to 5m vertically and an spectacular 100m horizontally.
With fittings that perfectly fit in existing Saniflo products, fitting is very simple with no need to alter your pipework - fit for a smaller cloakroom. Potential Connections: Toilet & Wash Basin.
With reduced running noise, discreet instillation behind a WC, and simple access for servicing and maintenance, you won't even notice the motor is there.
Similar to the original Saniflo Up but allows connection of a WC and a wash basin to one macerator pump
Removable Tank lid.
Fits behind a WC
190mm depth required behind the WC.
Decreased noise levels of 46Dba sound pressure - the quietest in the market
5-year guarantee
Improved design of casing
One top waste inlet
A quiet motor for unobtrusive use
Connection for handbasin and WC
Single waste inlet on top of unit
Technical Information:
Pump (Vertically): 5 metres
Pump (Horizontally):100 metres
Discharge & Pipework: 22/28/32mm
Inlet Pipework: 40mm
Motor Power: 400 Watts
Flow Rates: 80 litres/min
Selecting the right sort of Pump is a key decision. After you decide that Macerators deliver the correct answer then the Sanitop Up Macerator Small Bore Pumping System - 6002 is no doubt worth seriously thinking about.
